Designed with a compact footprint and extended top surface, the Turbo Air TCBE-36SDR-E-N6 Super Deluxe chef base provides space for countertop equipment and undercounter refrigeration in one unit. The reinforced one-piece stainless steel top is insulated to prevent heat transfer and supports up to 788 pounds of equipment. Two stainless steel drawers with recessed handles accommodate one full-size and three sixth-size pans per drawer (pans not included), while drawer slides are built for consistent performance.
Outfitted with a self-contained, side-mounted refrigeration system, the Turbo Air TCBE-36SDR-E-N6 chef base operates between 33 and 38 degrees Fahrenheit using eco-friendly R600a hydrocarbon refrigerant. A digital temperature display is mounted to the front for quick reference. Its self-cleaning condenser helps prevent dust buildup by brushing the coil daily, and the hot gas condensate system reduces excess moisture inside the cabinet. High-density polyurethane insulation is foamed in place to promote cold air retention. The interior includes an anti-corrosion coated evaporator.
Excellent for grill stations and fast-paced kitchens needing refrigerated storage directly under countertop cooking equipment.
Specifications
| Manufacturer |
Turbo Air |
| Depth (in) |
33 |
| Height (in) |
25.25 |
| Hertz |
60 |
| NEMA |
5-15P |
| Number of Drawers |
2 |
| Phase |
1 |
| Product |
Chef Bases |
| Product Type |
Commercial Refrigeration |
| Rating |
Better |
| Refrigerant |
R600a (Hydrocarbon) |
| Sections |
1 |
| Series |
Super Deluxe |
| Special Features |
Casters Included - Uninstalled |
| Type |
Refrigerator |
| Voltage |
115 |
| Warranty |
5-year Parts & Labor, 7-year Compressor Parts |
| Width (in) |
41.63 |
| Weight |
251.00 |
Product Details
- Part of the Super Deluxe series
- 4.98-cu. ft. internal capacity
- Stainless steel front and side panels
- Reinforced 1-piece stainless steel top
- Top insulated to reduce heat transfer
- 2 stainless steel drawers with recessed handles
- Each drawer fits 1 full-size and 3 sixth-size pans up to 6 in. deep (pans not included)
- Top surface supports up to 788 lbs. of equipment
- 4-in. swivel casters
Warranty
5-year Parts & Labor, 7-year Compressor Parts
Documents
Refrigeration System
- Self-contained, side-mounted design
- Front-breathing configuration
- R600a hydrocarbon refrigerant
- Self-cleaning condenser
- Hot gas condensate system
- Anti-corrosion coated evaporator
- Front-mounted digital temperature display
- Temperature holding range: 33-38 degrees F
Dimensions & Utilities
- 41 5⁄8 in. W x 32 in. D x 20 1⁄4 in. H
- 2.8 A, 1⁄5 HP
- 115 V/60 Hz/1 ph, 9-ft. cord with NEMA 5-15P plug
Important Notes
*Nominal cubic footage measurements sometimes provided by refrigeration manufacturers may not indicate actual usable space. If you require a specific capacity, please call one of our customer care representatives to ensure the unit you order meets your needs.
*Image may not depict product color, inclusions or accessories.
*Free shipping on Turbo Air TCBE-36SDR-E-N6 within the 48 contiguous states.
Additional Product Information
Natural Refrigerant: Product made with Hydrocarbon Refrigerants
Casters Not Installed: Ships with casters that must be installed by end user
NEMA 5-15P: This product comes with a NEMA 5-15P plug
Cord Attached: This product includes a cord and plug
Food Pans Not Included: Food Pans are not included with this item
Certifications
C ETL US Listed: Tested by Intertek & found compliant with applicable U.S. & Canadian safety standards
ETL-Sanitation: Meets applicable ANSI/NSF sanitation standards in testing by Intertek
Super Deluxe Extended Top Chef Base Refrigerator, 41-5/8"W x 33"D x 25-1/4"H, 4.98 cu. ft., side mounted self-contained refrigeration system, self-cleaning condenser device, (2) durable drawers with recessed handles, accommodates pans up to 6" deep, capacity: (1) full size pan & (3) 1/6 size pans per drawer (NOT included), 16 ga. stainless steel one-piece reinforced insulated top, stainless steel front & sides, digital temperature display, R600a Hydrocarbon refrigerant, 1/5 HP, 115v/60/1-ph, 2.8 amps, NEMA 5-15P, cETLus, ETL-Sanitation
