Because the Turbo Air M3H47-2-TS heated cabinet is a reach-in model, it can be positioned against a wall. Its two lockable stainless steel doors provide direct access to the 10 universal tray slides, easing pan loading and retrieval. This 51 3⁄4-inch-wide by 32 1⁄8-inch-deep by 83-inch-high two-section unit features a stainless steel exterior and interior capable of withstanding high-volume use; this metal resists rust, corrosion, and wear and simplifies cleaning. To reduce injury risks, the cabinet's edges and corners are rounded, and for simple transport when cleaning or maintenance is required, it's positioned on 4-inch-diameter swivel casters; the two front casters can be locked during use.
For full visibility, the Turbo Air M3H47-2-TS heated cabinet's interior is lighted with LEDs. The 10 universal tray slides can each support one 6-inch-deep full-size pan, one 18-inch by 26-inch pan, two 14-inch by 18-inch pans, or three 12-inch by 20-inch pans. To hold various precooked dishes at safe temperatures, this unit produces and maintains temperatures from 140 to 180 degrees Fahrenheit with its ducted fan air distribution system. Staff can modify and manage temperatures with the digital temperature control and monitor system. To minimize the risk of temperature fluctuations, an alarm beeps to alert operators if the doors aren't closed properly. For further temperature preservation, the cabinet and doors are foamed-in-place with high-density, CFC-free polyurethane insulation.
Perfect for catering companies, banquet halls, and hotels needing to transport and hold prepared foods at safe serving temperatures.
Specifications
| Manufacturer |
Turbo Air |
| Application |
Heat Only |
| Color |
Silver |
| Construction |
Stainless Steel |
| Control Location |
Top |
| Controls |
Digital |
| Cubic Feet |
42.9 |
| Depth (in) |
30.75 |
| Door Design |
Full |
| Door Type |
Solid |
| Heat |
Electric |
| Height (in) |
83 |
| Hertz |
60 |
| Hinge Configuration |
Left/Right |
| kW |
1.55 |
| Load Type |
Reach In |
| NEMA |
5-15P |
| No. of Doors |
2 |
| Pan Capacity |
10 |
| Phase |
1 |
| Product |
Heated Cabinets |
| Product Type |
Food Warming Equipment |
| Sections |
2 |
| Series |
M3 |
| Size |
Full Height |
| Slide Type |
Universal |
| Type |
Insulated |
| Voltage |
115 |
| Warranty |
3-year Parts & Labor |
| Width (in) |
51.75 |
| Weight |
345.00 |
Product Details
- Part of the M3 series
- Interior volume: 42.9 cu. ft.
- Full-height, reach-in configuration with 2 sections
- Durable stainless steel exterior and interior
- Sturdy grille design
- (4) 4-in.-diameter swivel casters with locking front casters
- CFC-free, high-density polyurethane insulation is foamed in place
- Rounded edges and corners
- 2 hinged, solid stainless steel doors can be locked
- Replaceable 1-piece magnetic door gaskets
- LED interior lighting
- 10 universal tray slides
- Tray slide capacity: (1) 6-in.-deep full-size pan, (1) 18-in. x 26-in. pans, (2) 14-in. x 18-in. pans, or (3) 12-in. x 20-in. pans
- Operating temperature range: 140-180 degrees F
- Ducted fan air distribution system
- Digital temperature control and monitor system
- Alarm sounds when doors aren't sealed
- Digital display
- On/off switch on control panel
Warranty
3-year Parts & Labor
Documents
Dimensions & Utilities
- Interior: 45 1⁄4 in. W x 25 1⁄8 in. D x 58 3⁄4 in. H
- Overall: 51 3⁄4 in. W x 32 1⁄8 in. D x 83 in. H
- 13.5 A, 1550 W
- 115 V/60 Hz/1 ph, includes 8-ft. cord with NEMA 5-15P plug
Important Notes
*Image may not depict product color, inclusions or accessories.
*Free shipping on Turbo Air M3H47-2-TS within the 48 contiguous states.
Additional Product Information
NEMA 5-15P: This product comes with a NEMA 5-15P plug
Cord Attached: This product includes a cord and plug
Digital Controls: Digital displays are easy to use & see at a distance
Heat Only: Dry heat for warming items not requiring humidity
Insulated: Conserves energy and maintains cool-to-touch exterior
Full Height: Full-height design maximizes capacity in a single footprint
Full Doors: Doors spanning full height of unit allow for easy access to the entire cabinet
Certifications
ETL US Listed: Tested by Intertek & found compliant with applicable U.S. safety standards
ETL-Sanitation: Meets applicable ANSI/NSF sanitation standards in testing by Intertek
